Power Take Off

Firefly Fire Pumps Stand: 5/E180
  • Power Take Off
  • Power Take Off
  • Power Take Off
Power Take Off Power Take Off Power Take Off

Key Features



  • "LM Series FireHawk" Split Shaft PTO inline power take off are perfectly designed to transmit power & torque upto 160 HP vehicles.

  • Single Casing with Spur Gears for Smooth Operations

  • Installed in midship position between the truck transmission and & the rear axle.

  • Excellent Interchangeability and Easy Serviceability

  • Stronger Built With Oil Lubricated oversized bearing

  • Avalibility of Flanges as per vehicle Weight - 70 kg

  • High Quality Double lip oil Seals with Inbuilt water cooling systems

  • Additional provision of PTO Mounting Pads For Excellant vibration damping

  • Available Ratios - 1:1.33 & 1:1.48 *Other ratios can also be made available on request.

Key Features

  • "FM Series FireHawk" split shaft inline power take off are perfectly designed to transmit power & torque upto 300 HP vehicles.

  • Single Casing with Helical Gears for Smooth Operations

  • Installed in midship position between the truck transmission and & the rear axle.

  • Excellent Interchangeability and Easy Serviceability

  • Stronger Built With Oil Lubricated oversized bearing

  • Avalibility of Flanges as per vehicle Weight - 92.5 kg

  • High Quality Double lip oil Seals with Inbuilt water cooling systems

  • Additional provision of PTO Mounting Pads For Excellant vibration damping

  • Available in four different ratios (1:1.17, 1:1.31, 1:1.48, 1:1.62)

  • *Other ratios can also be made available on request.
